About the Product
This SSK750M model Stormshark can be pre-installed into a bespoke Ø 750mm fabricated chamber and has pipework connection options between 150mm to 225mm. Alternatively, this model is available as the separator only for installation into a pre-cast concrete chamber
The Specification of this model are as follows (excluding chamber)
- Overall Height – 1950mm
- Minimum Ø Chamber – 750mm
- Height to Inlet Centre – 1700mm
- Standard Pipework Connection – 150mm
- Sediment Storage Capacity – 0.47m³
- Oil/Debris Storage Capacity – 80 litres
- Weight – 50kg
We offer an alternative model that is larger and can fit into a bespoke Ø 1050mm chamber which you can see here
About Stormshark
The Stormshark is an Advanced Hydrodynamic Separator with a unique patented design with a proven and tested performance. Designed for use in SuDS treatment trains, providing certainty of water quality treatment, enabling enhanced amenity and biodiversity downstream. Protecting and defending downstream controlled waters from sediment-bound pollutants.
Design certification & testing
Performance
The Stormshark removes sediment bound contaminants. Available in differing sizes to suit site flows and conditions. The Stormshark removes over 50% of fine TSS (0-200 microns, median size 75 microns) at design flows and up to 99% of TDS 0.1 to 0.4mm (coarse)
